Crane and Forklift Camera

Wireless Crane Damping Camera Viewing system MC-1001-DPC

It is a wireless CCTV system designed for tower crane, crane vehicle,gantry, jib truck. The updated 10.1 inch comes with complete metal housing and IP67 waterprofe, it is working much more stable and suit for more complicated applications. The camera and monitor working range up to 500meters
  • Details
Features:

>10.1 inch metal and waterproof monitor with recorder
>720P recording,max. 128GB sd memory
>2.4G wireless, 500m working distance
>Control camera by monitor buttons
>Monitor 8V-40V wide power input, Camera 12V-30V power input
>30 times zoon in camera
>IP69K camera waterproof

>HD IMX307 Camera sensor


180 degree level


Camera size


Full view of camera

10.1inch monitor with build in recorder, Metal housing, IP68 waterproof

30 times zoom in and out


Specifications:



Monitor

Data

Screen size

10.1 inch

Ratio

16:9

Resolution

1024*600 (RGB)

Back light and brightness

LED,300cd/m2

Contrast

1000:1

View angle

UP-50°/ DOWN-70°/LEFT-70°/ RIGHT-70°

OSD

English

Display mode

1/2/4 windows display

Recording memory

Max. 128GB sd card

Max. working camera

4 channels

Working voltage

DC 5-40V

Power consumption

<5W

Max. current

<550mA

Working Temp.

-10 to 60 ºC

Recording Temp.

-20 to 70 ºC

Waterproof

IP67

2.4G working distance

1500 meters (receiving distance)

2.4g wireless frequency

2403-2480MHz

Camera

Data

Camera sensor

1/2.8'' CMOS imx307

Resolution

1920x1080

Level view angle

70.9～7.1°(wide view-zoom in)

Zoom Speed

About 3 seconds

Working voltage

DC12-30V

2.4G working distance

500 meters (transmit distance)

Waterproof

IP68
